AERATION EQUIPMENT
The heart of the continuous aeration system process is the “Mixing Head”, comprising a stator and a rotor assembled on a main shaft, manufactured entirely from 316 stainless steel.
For cleaning and drain-off reasons ,it is much better to put the head vertical.
The Converticoll Mixer only needs less than 1 square meter floor space.
The jacketed rotor and stator are both fitted with pins to ensure thorough mixing and distribution of the product/gas slurry.
A liquid phase and a gas phase merge at the inlet of the mixing head and are homogenized with accurate flow control under controlled pressure.
Infinite control of the variables – mixing action, system pressure, rate of flow and ratio between the liquid and gas phases, temperature etc. – provides for uniform texture, repeatable quality of product and not least versatility.
At the discharge of the mixing head the pressurized mixture of gas and liquid comes gradually and controlled into atmosphere , and expands into a foam.
Technical Data







Model
CVC50
CVC100
CVC500
CVC750
CVC1000
CVC2000
CVC3000
Electrical power standard
3 kW
4 kW
4 kW
7,5 kW
9,2 kW
15 kW
22 kW
Electrical supply 3ph - 50Hz







Product capacity l/hr
10-50
20-100
100-500
150-750
200-1000
400-2000
800-4000
Mixing head volume
0,55 l
1,10 l
1,73 l
2,83 l
3,10 l
5,50 l
8,00 l
Number of mixing pins
160
320
528
864
880
1600
2400
CONTINUOUS AERATOR
